lost the pin
Post Reply    Forum -> General Discussion 12Next
Author Message
Addicted
150 Sprint Veloce,Vespa GTS 300
Joined: 22 Feb 2010
Posts: 1002
Location: St Neots Cambridgeshire England
Sun Feb 02, 2020 6:06 am quote
Hi!
The speedo on my GTS today kept fogging up, so to clear it out, I removed the little rubber stopper that you use to set the clock, and yes, as you can guess, I dropped one of the little plastic pins that are attached to the rubber stopper ( there are two)

Anyone know what those pins are called, and where to get a spare one??

Cheers

Graham
Ossessionato
2009 GTV250 (Gone), 2003 Inder trailer, 2001 BMW R1100RT
Joined: 24 Jun 2009
Posts: 4130
Location: Santa Cruz California
Sun Feb 02, 2020 7:11 am quote
Try a dealer or af1 racing, scooterwest, ...

Best Miguel
Veni, Vidi, Posti
Lx 50 4T, GTS 250, Something Chinese
Joined: 21 Feb 2011
Posts: 7703
Location: KS USA
Sun Feb 02, 2020 2:02 pm quote
You may have to get a whole speedometer set.
Ossessionato
2009 GTV250 (Gone), 2003 Inder trailer, 2001 BMW R1100RT
Joined: 24 Jun 2009
Posts: 4130
Location: Santa Cruz California
Sun Feb 02, 2020 3:56 pm quote
Look in eBay
Addicted
150 Sprint Veloce,Vespa GTS 300
Joined: 22 Feb 2010
Posts: 1002
Location: St Neots Cambridgeshire England
Sun Feb 02, 2020 11:21 pm quote
Max6200 wrote:
You may have to get a whole speedometer set.
For just the little plastic pins? If I had a 3D printer, I could print out the pins myself! If I can't find anything suitable, I'll have to resort to using cocktail sticks!!

Graham
Veni, Vidi, Posti
Lx 50 4T, GTS 250, Something Chinese
Joined: 21 Feb 2011
Posts: 7703
Location: KS USA
Sun Feb 02, 2020 11:25 pm quote
louswheel wrote:
Max6200 wrote:
You may have to get a whole speedometer set.
For just the little plastic pins? If I had a 3D printer, I could print out the pins myself! If I can't find anything suitable, I'll have to resort to using cocktail sticks!!

Graham
Or toothpicks...
Molto Verboso
LXS 150
Joined: 13 Aug 2009
Posts: 1009
Location: The OTHER South Bay, CA
Mon Feb 03, 2020 12:14 am quote
Max6200 wrote:
louswheel wrote:
Max6200 wrote:
You may have to get a whole speedometer set.
For just the little plastic pins? If I had a 3D printer, I could print out the pins myself! If I can't find anything suitable, I'll have to resort to using cocktail sticks!!

Graham
Or toothpicks...
...saturated in thin cyanoacrylate adhesive (aka: CA glue or "Crazy Glue") for preservation. Lacquer or varnish might also work.
Addicted
150 Sprint Veloce,Vespa GTS 300
Joined: 22 Feb 2010
Posts: 1002
Location: St Neots Cambridgeshire England
Mon Feb 03, 2020 12:31 am quote
Rusty J wrote:
Max6200 wrote:
louswheel wrote:
Max6200 wrote:
You may have to get a whole speedometer set.
For just the little plastic pins? If I had a 3D printer, I could print out the pins myself! If I can't find anything suitable, I'll have to resort to using cocktail sticks!!

Graham
Or toothpicks...
...saturated in thin cyanoacrylate adhesive (aka: CA glue or "Crazy Glue") for preservation. Lacquer or varnish might also work.
That is a thought...... although my original problem at the time was that the bloody sppedo was fogging up most of the time, so maybe something like this? https://www.sip-scootershop.com/en/products/speedometerrev+counter+sip+_mv91402bj

Graham
Addicted
150 Sprint Veloce,Vespa GTS 300
Joined: 22 Feb 2010
Posts: 1002
Location: St Neots Cambridgeshire England
Mon Feb 03, 2020 12:43 am quote
dilemma...
Although, my other half of a brain, or indeed the little devil sitting on my shoulder is telling me to lose the old 2012 GTS and get this instead... https://www.scooters.co.uk/vespa-gts-300-abs-hpe-msc-special-edition/

Graham
Veni, Vidi, Posti
Lx 50 4T, GTS 250, Something Chinese
Joined: 21 Feb 2011
Posts: 7703
Location: KS USA
Mon Feb 03, 2020 12:44 am quote
louswheel wrote:
Rusty J wrote:
Max6200 wrote:
louswheel wrote:
Max6200 wrote:
You may have to get a whole speedometer set.
For just the little plastic pins? If I had a 3D printer, I could print out the pins myself! If I can't find anything suitable, I'll have to resort to using cocktail sticks!!

Graham
Or toothpicks...
...saturated in thin cyanoacrylate adhesive (aka: CA glue or "Crazy Glue") for preservation. Lacquer or varnish might also work.
That is a thought...... although my original problem at the time was that the bloody sppedo was fogging up most of the time, so maybe something like this? https://www.sip-scootershop.com/en/products/speedometerrev+counter+sip+_mv91402bj

Graham
Yep. We're all dying to get one of those. But they're so expensive. I don't have European money.
Veni, Vidi, Posti
Lx 50 4T, GTS 250, Something Chinese
Joined: 21 Feb 2011
Posts: 7703
Location: KS USA
Mon Feb 03, 2020 12:46 am quote
The one thing I really hate about the GTS instrument panel is that if I have polarized goggles on I can't see the digital part of it. It really sucks.
Ossessionato
BV350, Primavera 150, Yamaha Zuma 125
Joined: 06 Jun 2013
Posts: 2953
Location: The Twin Cities of Minneapolis/Saint Paul, Minnesota
Mon Feb 03, 2020 5:32 am quote
louswheel wrote:
Max6200 wrote:
You may have to get a whole speedometer set.
For just the little plastic pins? If I had a 3D printer, I could print out the pins myself! If I can't find anything suitable, I'll have to resort to using cocktail sticks!!

Graham
I just got a 3D printer and I'm like a kid with a new toy. Could you send pictures and measurements? I'd give it a try.
Addicted
150 Sprint Veloce,Vespa GTS 300
Joined: 22 Feb 2010
Posts: 1002
Location: St Neots Cambridgeshire England
Mon Feb 03, 2020 8:34 am quote
JKJ-FZ6 wrote:
louswheel wrote:
Max6200 wrote:
You may have to get a whole speedometer set.
For just the little plastic pins? If I had a 3D printer, I could print out the pins myself! If I can't find anything suitable, I'll have to resort to using cocktail sticks!!

Graham
I just got a 3D printer and I'm like a kid with a new toy. Could you send pictures and measurements? I'd give it a try.
I'll certantly give you the size of the thing, let me take a photo of it as well!
If successful, you could make a fortune selling the pins, co's I bet I'm not the only one losing the things!

Graham

That first sentence I wrote sounds wrong....!
Addicted
150 Sprint Veloce,Vespa GTS 300
Joined: 22 Feb 2010
Posts: 1002
Location: St Neots Cambridgeshire England
Mon Feb 03, 2020 9:04 am quote
[url=https://postimg.cc/XZkhksfr]
This is the pin next to the rubber bung that goes over the speedo face

[/url]

And here's the dimentions of the pin!

Hope you can see the dimentions

H 21mm
W 3mm
top of the "hat" say 3.2mm
length of the "hat 2mm

Graham
Ossessionato
BV350, Primavera 150, Yamaha Zuma 125
Joined: 06 Jun 2013
Posts: 2953
Location: The Twin Cities of Minneapolis/Saint Paul, Minnesota
Mon Feb 03, 2020 9:39 am quote
I'm guessing the purpose of the pins is to extend to push the switches?
Veni, Vidi, Posti
2007 LX 150 (memories)
Joined: 12 Jun 2007
Posts: 8232
Location: New Hampshire
Mon Feb 03, 2020 9:40 am quote
H 21mm
W 3mm
top of the "hat" say 3.2mm
length of the "hat 2mm

To put those into US decimals:

H .827
W .118
top of the "hat" say .126
length of the "hat" .079


Doesn't look right. only .004 on a side between the flange and the shank.

Recheck your hat diameter.
Addicted
150 Sprint Veloce,Vespa GTS 300
Joined: 22 Feb 2010
Posts: 1002
Location: St Neots Cambridgeshire England
Mon Feb 03, 2020 9:46 am quote
JKJ-FZ6 wrote:
I'm guessing the purpose of the pins is to extend to push the switches?
Yep, and they're like gold dust, as it the rubber bung!

Graham
Addicted
150 Sprint Veloce,Vespa GTS 300
Joined: 22 Feb 2010
Posts: 1002
Location: St Neots Cambridgeshire England
Mon Feb 03, 2020 9:49 am quote
NightWing wrote:
H 21mm
W 3mm
top of the "hat" say 3.2mm
length of the "hat 2mm

To put those into US decimals:

H .827
W .118
top of the "hat" say .126
length of the "hat" .079


Doesn't look right. only .004 on a side between the flange and the shank.

Recheck your hat diameter.
Will do, but I think the length of the pin is more important that the width of the "hat" as the "hat pushes into the hole in the rubber bung!

Graham
Ossessionato
Yamaha Tricity 155 Urban 2019 - MV Agusta 125 RS 1956 - Moto Guzzi Airone 250 Sport 1951
Joined: 21 Jul 2007
Posts: 2545
Location: Latina (Italy)
Mon Feb 03, 2020 10:35 am quote
... can you make it in metal ..?
Ossessionato
BV350, Primavera 150, Yamaha Zuma 125
Joined: 06 Jun 2013
Posts: 2953
Location: The Twin Cities of Minneapolis/Saint Paul, Minnesota
Mon Feb 03, 2020 11:04 am quote
Attila wrote:
... can you make it in metal ..?
Not at the moment. It will be white plastic.
Quote:
Doesn't look right. only .004 on a side between the flange and the shank.

Recheck your hat diameter.
Yes, it looks like the hat diameter is critical if the part must fit in holes in the rubber part. Also, check that the pin will fit though holes in the speedometer face, if there are any.


Ossessionato
BV350, Primavera 150, Yamaha Zuma 125
Joined: 06 Jun 2013
Posts: 2953
Location: The Twin Cities of Minneapolis/Saint Paul, Minnesota
Mon Feb 03, 2020 11:11 am quote
The printer's resolution isn't going to be that close anyway.
Veni, Vidi, Posti
2007 LX 150 (memories)
Joined: 12 Jun 2007
Posts: 8232
Location: New Hampshire
Mon Feb 03, 2020 11:23 am quote
I questioned the hat diameter because the photo seems to show a bigger difference in hat/shank diameter than .004 on a side.
Ossessionato
BV350, Primavera 150, Yamaha Zuma 125
Joined: 06 Jun 2013
Posts: 2953
Location: The Twin Cities of Minneapolis/Saint Paul, Minnesota
Mon Feb 03, 2020 11:32 am quote
NightWing wrote:
I questioned the hat diameter because the photo seems to show a bigger difference in hat/shank diameter than .004 on a side.
I see what you meant.

I'm afraid a part that small is not going to come out well on my printer, at least without some fine-tuning. In fact, the first attempt looks obscene. You might be better of with a stirring stick!


Veni, Vidi, Posti
2007 LX 150 (memories)
Joined: 12 Jun 2007
Posts: 8232
Location: New Hampshire
Mon Feb 03, 2020 11:42 am quote
JKJ-FZ6 wrote:
NightWing wrote:
I questioned the hat diameter because the photo seems to show a bigger difference in hat/shank diameter than .004 on a side.
I see what you meant.

I'm afraid a part that small is not going to come out well on my printer, at least without some fine-tuning. In fact, the first attempt looks obscene. You might be better of with a stirring stick!
I saw one like that in an adult toy store. It might have been bigger, though.
Ossessionato
BV350, Primavera 150, Yamaha Zuma 125
Joined: 06 Jun 2013
Posts: 2953
Location: The Twin Cities of Minneapolis/Saint Paul, Minnesota
Mon Feb 03, 2020 12:56 pm quote
louswheel wrote:
For just the little plastic pins? If I had a 3D printer, I could print out the pins myself! If I can't find anything suitable, I'll have to resort to using cocktail sticks!!

Graham
Golf tee?
Addicted
150 Sprint Veloce,Vespa GTS 300
Joined: 22 Feb 2010
Posts: 1002
Location: St Neots Cambridgeshire England
Mon Feb 03, 2020 1:30 pm quote
JKJ-FZ6 wrote:
louswheel wrote:
For just the little plastic pins? If I had a 3D printer, I could print out the pins myself! If I can't find anything suitable, I'll have to resort to using cocktail sticks!!

Graham
Golf tee?
You might have a solution! I wonder how thick they are? If they're too thick, they might not fit in the little holes near the clock! They must be no thicker than 3mm!

Graham
Molto Verboso
GTS 250i.e.
Joined: 12 Jun 2008
Posts: 1381
Location: Sunshine Coast, Australia
Mon Feb 03, 2020 1:37 pm quote
To get the fog out, place a packet of desicant beads over the clock button hole and seal over with cling film. A few days and it will draw out the moisture.
Member
2019 Vespa Primavera Touring Rosso Vignola
Joined: 19 Sep 2018
Posts: 28
Location: Alabaster, Alabama
Mon Feb 03, 2020 3:28 pm quote
Do you have a hobby shop that sells plastic models and model railroad equipment? They will have styrene plastic rods and tubes that you can glue together and make what you need. Take your example with you and compare sizes.
Enthusiast
2009 GTS 250 "Noa"
Joined: 13 Oct 2019
Posts: 86
Location: Canada
Mon Feb 03, 2020 6:13 pm quote
4mm ABS rod. Insert in a drill to turn down to size with some sandpaper.
Veni, Vidi, Posti
09 GTS (sold) 2014 NC700XD
Joined: 02 Jul 2008
Posts: 5002
Location: Charlotte, NC
Mon Feb 03, 2020 6:15 pm quote
JKJ-FZ6 wrote:
NightWing wrote:
I questioned the hat diameter because the photo seems to show a bigger difference in hat/shank diameter than .004 on a side.
I see what you meant.

I'm afraid a part that small is not going to come out well on my printer, at least without some fine-tuning. In fact, the first attempt looks obscene. You might be better of with a stirring stick!
I have a printer in the classroom, if you send me the file in .stl format I can give it a shot too. PM me if you think itís worth a try...
Ossessionato
BV350, Primavera 150, Yamaha Zuma 125
Joined: 06 Jun 2013
Posts: 2953
Location: The Twin Cities of Minneapolis/Saint Paul, Minnesota
Mon Feb 03, 2020 8:52 pm quote
Experimenting...
Printed on its side this time. One side is slightly flattened, and it has a larger diameter "hat" at each end (due to a slip-up in my CAD design) but it's much better. The actual diameter of the end is about 3.25mm. I'm not sure that the diameter is right yet because, as NightWing says, there's too little difference between the end and shank diameters.


Molto Verboso
LXS 150
Joined: 13 Aug 2009
Posts: 1009
Location: The OTHER South Bay, CA
Tue Feb 04, 2020 12:51 am quote
louswheel wrote:
That is a thought...... although my original problem at the time was that the bloody sppedo was fogging up most of the time, so maybe something like this? https://www.sip-scootershop.com/en/products/speedometerrev+counter+sip+_mv91402bj

Graham
Looks sharp!
louswheel wrote:
Although, my other half of a brain, or indeed the little devil sitting on my shoulder is telling me to lose the old 2012 GTS and get this instead... https://www.scooters.co.uk/vespa-gts-300-abs-hpe-msc-special-edition/

Graham
That's also quite impressive. Slightly different budget involved, but hey -- you have a pretext now.

Kind of like taking your bike in and getting an Eu5.000,00 oil change where they throw in a new bike for free.
Veni, Vidi, Posti
09 GTS (sold) 2014 NC700XD
Joined: 02 Jul 2008
Posts: 5002
Location: Charlotte, NC
Tue Feb 04, 2020 3:44 am quote
JKJ-FZ6 sent over his design, here is what my printer came up with... The bottom (hat) is a wee bit wider than the rest, it may not look like it on the picture because of the downward perspective.

Let me know if you want it.


Addicted
150 Sprint Veloce,Vespa GTS 300
Joined: 22 Feb 2010
Posts: 1002
Location: St Neots Cambridgeshire England
Tue Feb 04, 2020 4:10 am quote
yeah, I'll have a look at it, although it might be a bit of bother send ing it to me as I'm in the UK!

Graham
Addicted
150 Sprint Veloce,Vespa GTS 300
Joined: 22 Feb 2010
Posts: 1002
Location: St Neots Cambridgeshire England
Tue Feb 04, 2020 4:31 am quote
Eureka!
Thanks to everyone who helped in this matter, but the old British ingenuity came through!
I used a cotton bud, snipped it to the correct length, and screwed a very small screw to give it it's top hat- an added extra is that if it gets lodged in the small hole where the pin goes in, a magnet will soon get it out!
Take that Piaggio!!


Graham
Ossessionato
2009 GTS 250, 2013 Buddy 125, 2014 Triumph Bonneville
Joined: 23 Apr 2016
Posts: 2010
Location: North Jersey
Tue Feb 04, 2020 5:05 am quote
I bet the golf tee would have worked. If it was too wide or too long, just sand it down to proper size.
Ossessionato
Yamaha Tricity 155 Urban 2019 - MV Agusta 125 RS 1956 - Moto Guzzi Airone 250 Sport 1951
Joined: 21 Jul 2007
Posts: 2545
Location: Latina (Italy)
Tue Feb 04, 2020 5:15 am quote
... I never understood if the spare part was available and at what price ...
I guess this DIY essay is also for personal satisfaction.
However we work better with the metric system.
Addicted
150 Sprint Veloce,Vespa GTS 300
Joined: 22 Feb 2010
Posts: 1002
Location: St Neots Cambridgeshire England
Tue Feb 04, 2020 7:22 am quote
Attila wrote:
... I never understood if the spare part was available and at what price ...
I guess this DIY essay is also for personal satisfaction.
However we work better with the metric system.
I found it frustrating trying to find such a small part, - I couldn't even find the small bung that covers the clock on the speedo!

I haven't found a place out there that sells such parts for the Vespa GTS!

Graham
Ossessionato
BV350, Primavera 150, Yamaha Zuma 125
Joined: 06 Jun 2013
Posts: 2953
Location: The Twin Cities of Minneapolis/Saint Paul, Minnesota
Tue Feb 04, 2020 7:47 am quote
I suspect Piaggio buys the speedometers from a third party as an assembly, and it's the Smallest Replaceable Unit from Piaggio. If there was a huge demand for these pins some supplier would put them on the market. Otherwise you must make your own.
Ossessionato
1991 T5 Pole Position, 2008 LXS 125, 2013 Peugeot Metropolis RS
Joined: 06 May 2011
Posts: 3281
Location: Staffordshire UK
Tue Feb 04, 2020 9:39 am quote
cotton pickin' problem solved!
Cross Egypt Challenge - A 2400km ride throughout Egypt   Vespa Wasp Pin Badges   AF1 Racing Vespa Austin
Post Reply    Forum -> General Discussion 12Next
[ Time: 0.1982s ][ Queries: 28 (0.0472s) ][ Debug on ]
