Wed Aug 17, 2022 8:41 am

Ossessionato
P208, Stella VMC Stelvio 187, Stella 150, VNX1T, V9A1T, V9B1T, 02 Sportster XLH1208
Joined: 20 Jul 2018
Posts: 3985
Location: Staten Island, NY

Ossessionato
P208, Stella VMC Stelvio 187, Stella 150, VNX1T, V9A1T, V9B1T, 02 Sportster XLH1208
Joined: 20 Jul 2018
Posts: 3985
Location: Staten Island, NY
Wed Aug 17, 2022 8:41 am linkquote
Looking at upgrading carb finally to side draft.

Exploring what is out there in terms of intake manifolds for the LML cases and wondering which ones others have used? Any issues with something like this with the LML reed block cases?
https://www.sip-scootershop.com/en/product/carburettor-kit-malossi-phbh-30-with-manifold-kit-x360-reed-valve-2012_16158950?q=carb%20kit%20px

I am also looking at the MMW intake manifold that specifically states designed for these cases but its $$ and lead time made to order.

https://www.sip-scootershop.com/en/product/intake-manifold-mmw-36mm-reed-valve-casing-lml_40808J00

What about fitment under the cowl with different carbs, PHBH, VHST and jamming a fuel pump in there?
Wed Aug 17, 2022 12:44 pm

Ossessionato
2007 Stella 225
Joined: 02 Nov 2019
Posts: 3047
Location: Rochester, Minnesota

Ossessionato
2007 Stella 225
Joined: 02 Nov 2019
Posts: 3047
Location: Rochester, Minnesota
Wed Aug 17, 2022 12:44 pm linkquote
Look up MRP on SIP, I have one and it fit with no issues.
Wed Aug 17, 2022 12:59 pm

Ossessionato
P208, Stella VMC Stelvio 187, Stella 150, VNX1T, V9A1T, V9B1T, 02 Sportster XLH1208
Joined: 20 Jul 2018
Posts: 3985
Location: Staten Island, NY

Ossessionato
P208, Stella VMC Stelvio 187, Stella 150, VNX1T, V9A1T, V9B1T, 02 Sportster XLH1208
Joined: 20 Jul 2018
Posts: 3985
Location: Staten Island, NY
Wed Aug 17, 2022 12:59 pm linkquote
Christopher_55934 wrote:
Look up MRP on SIP, I have one and it fit with no issues.
Did you get the mrp one that says for LML? Plug that oiler hole or does the intake block not even cover it?
Wed Aug 17, 2022 1:15 pm

Ossessionato
2007 Stella 225
Joined: 02 Nov 2019
Posts: 3047
Location: Rochester, Minnesota

Ossessionato
2007 Stella 225
Joined: 02 Nov 2019
Posts: 3047
Location: Rochester, Minnesota
Wed Aug 17, 2022 1:15 pm linkquote
swiss1939 wrote:
Did you get the mrp one that says for LML? Plug that oiler hole or does the intake block not even cover it?
I got one for a P200, and plugged the hole.
Wed Aug 17, 2022 4:11 pm

Lucky
76 Sprint V, 63 GL, 62 VBB, 05 Stella, 66 Smallstate, 08 Stella (for now)
Joined: 16 Jun 2011
Posts: 6498
Location: Nashville

Lucky
76 Sprint V, 63 GL, 62 VBB, 05 Stella, 66 Smallstate, 08 Stella (for now)
Joined: 16 Jun 2011
Posts: 6498
Location: Nashville
Wed Aug 17, 2022 4:11 pm linkquote
I have an MMW block and VForce4 reeds in it. Vader sold me the block back long ago and far away, and it's served me well since.

I still found that I needed to do some more grinding to match the reed block opening to the top of the block for the VForce4's, but other than that, it's been good.

It's a really solid piece of kit and it's nice that you can buy different sizes of manifolds, so I've been able to just buy that one part when I upped my carb size.
Wed Aug 17, 2022 6:12 pm

Ossessionato
Joined: 26 Oct 2015
Posts: 3749


Ossessionato
Joined: 26 Oct 2015
Posts: 3749

Wed Aug 17, 2022 6:12 pm linkquote
I have the MMW on my cutdown T5 track bike. To get the clearance for the carb I had to make a 3/4" thick aluminum spacer that gets sandwiched between the engine case and the MMW block. Without that spacer, my carb's float bowl would hit the plastic cylinder shroud. And since my carb was then higher than normal, I raised my cowls (that I cut down) up about another 1". I also welded in an additional rear shock spacer to the frame. I think it's about 1.5" tall? I also used a CB160 center tank so I wouldn't have to worry about a fuel pump.







Wed Aug 31, 2022 4:49 am

Ossessionato
P208, Stella VMC Stelvio 187, Stella 150, VNX1T, V9A1T, V9B1T, 02 Sportster XLH1208
Joined: 20 Jul 2018
Posts: 3985
Location: Staten Island, NY

Ossessionato
P208, Stella VMC Stelvio 187, Stella 150, VNX1T, V9A1T, V9B1T, 02 Sportster XLH1208
Joined: 20 Jul 2018
Posts: 3985
Location: Staten Island, NY
Wed Aug 31, 2022 4:49 am linkquote
Bought a used VHSB 34 QD carb on ebay, missing some parts for cheap.

Missing throttle cable screw that attaches to top of slide, lid needs replacing, missing throttle spring, needle is bent, and its seriously gunked up so needs some time in the ultrasonic cleaner.

I spent about an hour just scraping solid goo out of some of the larger passages and then swabbing with alcohol and cotton swabs.

Parts missing/broken is about $150 (if I go with the fancy metal rotating cable lid).. so total I'd be into it around $240.

Jetting included:

choke jet: 60
inner pilot jet: B30
outer pilot jet: 30
needle: K27
needle jet: 266FN
needle seat: 150
main jet: 165

Also came with 9 extra main jets in a case. a few duplicates.


















k27 needle


5.2 gram floats



Last edited by swiss1939 on Wed Aug 31, 2022 6:53 am; edited 1 time in total
Wed Aug 31, 2022 6:29 am

Ossessionato
P208, Stella VMC Stelvio 187, Stella 150, VNX1T, V9A1T, V9B1T, 02 Sportster XLH1208
Joined: 20 Jul 2018
Posts: 3985
Location: Staten Island, NY

Ossessionato
P208, Stella VMC Stelvio 187, Stella 150, VNX1T, V9A1T, V9B1T, 02 Sportster XLH1208
Joined: 20 Jul 2018
Posts: 3985
Location: Staten Island, NY
Wed Aug 31, 2022 6:29 am linkquote
I find it interesting this carb came from a racing go kart. Lots of different use cases for the same types of carbs!


266FN atomizer


165 MJ


30 outer pilot


B30 inner pilot


60 choke jet


160, 162x2, 165, 170, 172x2, 178, 180 main jets



Wed Aug 31, 2022 7:57 am

Lucky
76 Sprint V, 63 GL, 62 VBB, 05 Stella, 66 Smallstate, 08 Stella (for now)
Joined: 16 Jun 2011
Posts: 6498
Location: Nashville

Lucky
76 Sprint V, 63 GL, 62 VBB, 05 Stella, 66 Smallstate, 08 Stella (for now)
Joined: 16 Jun 2011
Posts: 6498
Location: Nashville
Wed Aug 31, 2022 7:57 am linkquote
I think we tend to forget that the Largefame Vespa world is relatively unique in that we don't use side draft carbs by default. Even the smallie is a side draft.

Which means there are a TON of options out there if you want to match the carb to requirements, and not just size or PHBH vs. PWK.
Wed Aug 31, 2022 12:07 pm

Ossessionato
P208, Stella VMC Stelvio 187, Stella 150, VNX1T, V9A1T, V9B1T, 02 Sportster XLH1208
Joined: 20 Jul 2018
Posts: 3985
Location: Staten Island, NY

Ossessionato
P208, Stella VMC Stelvio 187, Stella 150, VNX1T, V9A1T, V9B1T, 02 Sportster XLH1208
Joined: 20 Jul 2018
Posts: 3985
Location: Staten Island, NY
Wed Aug 31, 2022 12:07 pm linkquote
Interesting article on the swappable venturi inserts/bushings in the VHSB 34 carb.

http://www.kartingasia.com/2007/rotax-max-carburetor-venturi-inserts-8-512-5/
