@108 avatar
UTC

Ossessionato
PX 200
Joined: UTC
Posts: 2304

Ossessionato
@108 avatar
PX 200
Joined: UTC
Posts: 2304
UTC quote
jimscoot wrote:
Hi Jack. I've noticed your using a helical cut gear primary.
I've always been confused as to what is the better option (pros, cons etc) between straight cut and helical cut gears, what are your thoughts on this?
Ran on straight teeth for a good 3 years installing it without understanding what I was installing at the time... I had the malossi 24/63 combo and needed to swap my clutch and primary out, so I thought why not...

Theres definitely more noise coming out of the primary and clutch, that's with the full metal to metal contact...

When you cycle through the gears its a lot more crunchy with the engagement, but definitely more solid transmission of power... feels like there's less dip in revs between gears.

I was quite comfortable cruising on short highway stints.

The primary seemed bulletproof, not much metal wear in the oil.

But eventually I went back to DRT helical stock gearing 23/65 the biggest reason because I wanted a shorter gear setup (higher gear ratio) and as far as I can see, there's not that many short gear options for straight teeth clutch and primary (all race use I imagine)

So with helical you get less noise and a smoother, softer shift (which is better for me riding around the city)...

Just my none scientific experience, question hijack over...
OP
UTC

Jet Eye Master
PX221 MHR, O tuned PX200, PX181 Quattrini and some motorbikes
Joined: UTC
Posts: 4437
Location: London UK

Jet Eye Master
PX221 MHR, O tuned PX200, PX181 Quattrini and some motorbikes
Joined: UTC
Posts: 4437
Location: London UK
UTC quote
jimscoot wrote:
Jack221 wrote:
Plenty of traffic here. Lockdown, Teir4 or not. Dodging it is half the fun.

For those in doubt whether a Cosa superstrong basket is worth the investment. Here is mine after 6 years, maybe 10,000 miles and with various tunes between 30 to 50bhp. Ridden like I stole it most of the time too.
Hi Jack. I've noticed your using a helical cut gear primary.
I've always been confused as to what is the better option (pros, cons etc) between straight cut and helical cut gears, what are your thoughts on this?
I really think it doesn't matter so much. Gearing in mine is total stock. 23/65 with 35 tooth. Helical is stronger and smoother but more friction and higher side load. Straight cut is kinder to the bearings but weaker. And so noisy. Like most things scooter, is personal choice and no right answer.
OP
UTC

Jet Eye Master
PX221 MHR, O tuned PX200, PX181 Quattrini and some motorbikes
Joined: UTC
Posts: 4437
Location: London UK

Jet Eye Master
PX221 MHR, O tuned PX200, PX181 Quattrini and some motorbikes
Joined: UTC
Posts: 4437
Location: London UK
UTC quote
charlieman22 wrote:
Thoughts from 50K feet.
- 4 post seize says heat expansion of piston vs cylinder studs.
- Failed WOT so fuel starvation or:
- Could be question of piston limits - those MHR are full of variating thickness. Any further work would only create more chance of piston deformation.
- Failure of oil delivery - but assume you are running premix
- Float bowl sucked dry? Longish WOT, hill that made carb at steeper angle. Have you played with float height recently for other purposes?

Putting breaks on gently - but due to piston swelling.
My only experience with piston swelling seizes are that they are immediate and unfriendly.
That kinda raises an eyebrow - its different at least.

Those would be on my list - and are probably already on yours...
The funniest thing about the seize was there are no detonation marks. Head still like new. Must have been too weak to pink properly. There was no sounds and it felt a bit dead over 80. While I was thinking 'this is weird' it seized. Can only be fuel starvation. That was the third time it had been over 80 that day. Was maybe just lucky before. Piston marks were straight overheat at the exhaust port. Usual for running weak.

It can only be something between tank and carb. There is a pump and two fuel filters and a load of pipes. Something wrong right there.
⬆️    About 1 year elapsed    ⬇️
OP
UTC

Jet Eye Master
PX221 MHR, O tuned PX200, PX181 Quattrini and some motorbikes
Joined: UTC
Posts: 4437
Location: London UK

Jet Eye Master
PX221 MHR, O tuned PX200, PX181 Quattrini and some motorbikes
Joined: UTC
Posts: 4437
Location: London UK
UTC quote
Not updated this for a while. New 57 MHR kit on new 60mm crank to rebuild from the seize. 65 helical gear wore loose in the primary too. Changed to 24/62 straight cut primary with 36 tooth 4th, because the 35 had worn out too.
At a guess I've done 3000 miles on this rebuild already and is due another this winter. Going to need new clutch plates/springs soon as an interim fix but that's just a service item on this thing.

Anyway, weird issue. The other day it was making a tinkling noise while idling, like something loose, similar to a primary cush plate starting to come off. Later the same day it started backfiring at 6000 rpm and not revving more. Thinking it was not my day and the Kytronic had failed too, I removed it and took off the flywheel to change the timing to static. To my surprise the spark coil had fell off. Thought that's the issue bolted it up ran it again no difference. Long story short, the pickup has been hammered by the rivet and is broken. Changed the stator to another and all good at 10000rpm again.
Never seen this happen before
Never seen this happen before
Thought I was so clever
Thought I was so clever
@chandlerman avatar
UTC

Lucky
76 Sprint V, 63 GL, 62 VBB, 05 Stella, 66 Smallstate
Joined: UTC
Posts: 9393
Location: Nashville

118 Days Since Last Explosion

Lucky
@chandlerman avatar
76 Sprint V, 63 GL, 62 VBB, 05 Stella, 66 Smallstate
Joined: UTC
Posts: 9393
Location: Nashville

118 Days Since Last Explosion
UTC quote
It never ceases to amaze me the new and different ways these things break, especially the highly-tuned ones. It's a good thing they're so much fun to ride when they're wound up so tight to make the effort all worth it.
⬆️    About 4 months elapsed    ⬇️
OP
UTC

Jet Eye Master
PX221 MHR, O tuned PX200, PX181 Quattrini and some motorbikes
Joined: UTC
Posts: 4437
Location: London UK

Jet Eye Master
PX221 MHR, O tuned PX200, PX181 Quattrini and some motorbikes
Joined: UTC
Posts: 4437
Location: London UK
UTC quote
Been riding the 221 often. Would guess a few thousand miles over the summer been going good and solid.
Rode it Thursday all good. Wheeled it out today, wouldn't idle and was racing. Pulling choke again slowed it down. Blocked pilot jet it wasn't. It would appear to be some massive and sudden air leak.
Winter rebuild might be a few months early. Will investigate tomorrow. Pressure test first plan.
@108 avatar
UTC

Ossessionato
PX 200
Joined: UTC
Posts: 2304

Ossessionato
@108 avatar
PX 200
Joined: UTC
Posts: 2304
UTC quote
Interested to see what it is.

Winter overhaul it is it seems
OP
UTC

Jet Eye Master
PX221 MHR, O tuned PX200, PX181 Quattrini and some motorbikes
Joined: UTC
Posts: 4437
Location: London UK

Jet Eye Master
PX221 MHR, O tuned PX200, PX181 Quattrini and some motorbikes
Joined: UTC
Posts: 4437
Location: London UK
UTC quote
Took the carb and exhaust off. Disconnected the fuel pump pipe. Installed bungs. Connected the pump. Waited for the big hiss and nothing. 8 psi for many minutes. WTF. Nothing to see here.

Ok, fourth strip down of the 38. Pilot jet clear. Inner pilot jet clear (yes, these carbs have two pilot jets). Blew carb cleaner through the body from the float bowl. Same as yesterday, spraying into the Venturi from both outlets. Starting to struggle for ideas. Held the carb up shining a torch into the Venturi and can't see a clear round hole, there's something in it. Poked around with some soft wire. Looked again and clear. Reassembled and working fine. Drama over. Took for a celebratory thrash round the block, popping over 80 on the bypass.

Edit: Winter rebuild to include a fly side bearing. The one in it is looser than a retired madam.
@qascooter avatar
UTC

Ossessionato
79 P200E (Ruby), 62 Allstate (B-62)
Joined: UTC
Posts: 4167
Location: Florence, OR

Ossessionato
@qascooter avatar
79 P200E (Ruby), 62 Allstate (B-62)
Joined: UTC
Posts: 4167
Location: Florence, OR
UTC quote
Wooohooo! 4th times a charm. Clap emoticon Clap emoticon

EDIT: and I gotta say, I appreciate you going through what the problem was and the steps to make it work. And sometimes it takes going over everything a number of times, even for Jet-Eye Jack! Razz emoticon
⬆️    About 6 months elapsed    ⬇️
OP
UTC

Jet Eye Master
PX221 MHR, O tuned PX200, PX181 Quattrini and some motorbikes
Joined: UTC
Posts: 4437
Location: London UK

Jet Eye Master
PX221 MHR, O tuned PX200, PX181 Quattrini and some motorbikes
Joined: UTC
Posts: 4437
Location: London UK
UTC quote
Ok, it's time. 221 engine is out and split. There is a whole catalogue of stuff wrong with it. However it was still going fine; properly fast, reliable (still going on 50 mile round trips), smooth and easy to ride, no clutch or box issues. It was dripping oil but many do.

Once split it was surprising. Piston (vertex) had a crack in the underside, clutch cover leaking, gear oil minor seeping from one case bolt behind the stator, oil seeping from the head bolts, fly side bearing now badly worn (0.5mm radial), rear wheel bearings both beyond acceptable, low compression, cruciform as bad as the last and kick start buffer nearly through.

Gear oil level was full. Pre split pressure test holding good.

No more tuning, just repair and get going again before one of the others breaks.
It's a tough job being the cruciform in this scooter. Not jumping gear!
It's a tough job being the cruciform in this scooter. Not jumping gear!
@chandlerman avatar
UTC

Lucky
76 Sprint V, 63 GL, 62 VBB, 05 Stella, 66 Smallstate
Joined: UTC
Posts: 9393
Location: Nashville

118 Days Since Last Explosion

Lucky
@chandlerman avatar
76 Sprint V, 63 GL, 62 VBB, 05 Stella, 66 Smallstate
Joined: UTC
Posts: 9393
Location: Nashville

118 Days Since Last Explosion
UTC quote
I literally explained to people twice this week that the higher the state of tune, the more frequent and extensive the rebuilds, even if nothing has materially broken along the way.

That cruciform has definitely seen better days, though. That's some well-earned wear. Razz emoticon
OP
UTC

Jet Eye Master
PX221 MHR, O tuned PX200, PX181 Quattrini and some motorbikes
Joined: UTC
Posts: 4437
Location: London UK

Jet Eye Master
PX221 MHR, O tuned PX200, PX181 Quattrini and some motorbikes
Joined: UTC
Posts: 4437
Location: London UK
UTC quote
That MJ9 hardened cruciform was new in Nov 21. I'd guess 3000 miles, no more than 5. I'll check the old MOTs.
This time I have a hardened BFA one but that was as the one in 2020, and ended the same way. Surprised the cogs are still good. Last time it had a new 4th though.
It's just so tuned. Fastest PX I've ever ridden. When I describe it to people, the only comparison I have, is just like a stock 350LC. I used to have one and it's a fair comparison. I'm waiting for the cases to break. Have to be so careful I never miss a gear change.
@108 avatar
UTC

Ossessionato
PX 200
Joined: UTC
Posts: 2304

Ossessionato
@108 avatar
PX 200
Joined: UTC
Posts: 2304
UTC quote
Looks like you found the air leak.

Strange the pressure test didn't spot the leaky head.

That cruciform looks like it's seen a gear shift or two.
OP
UTC

Jet Eye Master
PX221 MHR, O tuned PX200, PX181 Quattrini and some motorbikes
Joined: UTC
Posts: 4437
Location: London UK

Jet Eye Master
PX221 MHR, O tuned PX200, PX181 Quattrini and some motorbikes
Joined: UTC
Posts: 4437
Location: London UK
UTC quote
108 wrote:
Looks like you found the air leak.

Strange the pressure test didn't spot the leaky head.

That cruciform looks like it's seen a gear shift or two.
That's not just any old cruciform. MJ9 hardened
https://www.sip-scootershop.com/en/product/cruciform-serie-pro-by-mj9_87029100
After the last BFA hardened one didn't last a year, I thought it would be worth a try. Just the same. Back to BFA again.
https://www.sip-scootershop.com/en/product/cruciform-sip-bfa_87095100
The head bolt leaks were spooge dribble. Pretty much nothing stops spooge leaking out when running 13.5:1. Only 4 studs, at full temperature, weren't designed for this.
UTC

Molto Verboso
One or two fun scoots....nothing too precious
Joined: UTC
Posts: 1973
Location: UK (South East)

Molto Verboso
One or two fun scoots....nothing too precious
Joined: UTC
Posts: 1973
Location: UK (South East)
UTC quote
Jack221 wrote:
That's not just any old cruciform. MJ9 hardened
https://www.sip-scootershop.com/en/product/cruciform-serie-pro-by-mj9_87029100
After the last BFA hardened one didn't last a year, I thought it would be worth a try. Just the same. Back to BFA again.
https://www.sip-scootershop.com/en/product/cruciform-sip-bfa_87095100
The head bolt leaks were spooge dribble. Pretty much nothing stops spooge leaking out when running 13.5:1. Only 4 studs, at full temperature, weren't designed for this.
Any good? https://www.sip-scootershop.com/en/product/lock-nut-m8-mm-gas-tight_87181100?q=gas%20tight
OP
UTC

Jet Eye Master
PX221 MHR, O tuned PX200, PX181 Quattrini and some motorbikes
Joined: UTC
Posts: 4437
Location: London UK

Jet Eye Master
PX221 MHR, O tuned PX200, PX181 Quattrini and some motorbikes
Joined: UTC
Posts: 4437
Location: London UK
UTC quote
Nice find. Amazing what sip sells. Upper temperature is a concern but worth a try.
