The scoot came to me looking kind of sad in 2017 i guess. No paperwork and non-runner. Looks like it was painted with a brush. Partly disassembled but fortunately had the parts with it.
External inline image provided by member with no explanatory text

External inline image provided by member with no explanatory text

External inline image provided by member with no explanatory text

External inline image provided by member with no explanatory text

External inline image provided by member with no explanatory text

External inline image provided by member with no explanatory text

The tank has likely been swapped at some point.
External inline image provided by member with no explanatory text

The scoot sat in the shed until I got info on the paperwork in 2021. After that it was time to fix some electrical gremlins.
External inline image provided by member with no explanatory text

External inline image provided by member with no explanatory text

Put some bearing balls back to where they belong.
External inline image provided by member with no explanatory text

And get the engine running again.
External inline image provided by member with no explanatory text

Patch the hole
External inline image provided by member with no explanatory text

External inline image provided by member with no explanatory text

External inline image provided by member with no explanatory text

External inline image provided by member with no explanatory text

Off to the inspection and back with a plate. Had to take the EU plate first since they do not have black ones in stock for some weird reason...
Black plates were standard in Finland before switching to white ones in 1970's. If a motorbike is -74 or older it could have been sold with a black plate. Thus ordering an old style black plate is just a matter of filling a form and payment of 8eur.
External inline image provided by member with no explanatory text

Much better
External inline image provided by member with no explanatory text

Decided to fix just some little things...
External inline image provided by member with no explanatory text

... but got completely carried away and disassembled the whole thing to patch up some extra holes.
External inline image provided by member with no explanatory text

Some hot snot on the edge of the legshield
External inline image provided by member with no explanatory text

External inline image provided by member with no explanatory text

External inline image provided by member with no explanatory text

And grinded to a level
External inline image provided by member with no explanatory text

External inline image provided by member with no explanatory text

Small parts after bead blasting
External inline image provided by member with no explanatory text

Local powdercoaters doing their magic
External inline image provided by member with no explanatory text

External inline image provided by member with no explanatory text

External inline image provided by member with no explanatory text

Time to assemble!
External inline image provided by member with no explanatory text

On goes the beading
External inline image provided by member with no explanatory text

Runners were a pain in the butt to fit. They requried bending, cutting and drilling to get the holes lined up.
External inline image provided by member with no explanatory text

Gray rubber-liners look great with the new color
External inline image provided by member with no explanatory text

In go the runner-rubbers along some soapy water
External inline image provided by member with no explanatory text

External inline image provided by member with no explanatory text

Time to pull the wires, cables and to whip out the gray parts
External inline image provided by member with no explanatory text

External inline image provided by member with no explanatory text

Assembling the fork was a nightmare, but worked out in the end.
External inline image provided by member with no explanatory text

Headset on along the handlebars
External inline image provided by member with no explanatory text

Standing on her own again (on one paw though)
External inline image provided by member with no explanatory text

Moved to a safer location to fit the engine and oil up the cables.
External inline image provided by member with no explanatory text

I kind of dislike the look of the engine with the color-matched cowls.
External inline image provided by member with no explanatory text

Looks like a scoot again
External inline image provided by member with no explanatory text

Getting there
External inline image provided by member with no explanatory text

Learned how to rivet aluminum just because of this thing. Turned out nice.
External inline image provided by member with no explanatory text

Speedo "glass" had seen better days
External inline image provided by member with no explanatory text

Disassembly was a pain but the result is definitely worth the trouble.
External inline image provided by member with no explanatory text

Out goes the finished scoot in to the Finnish winter
External inline image provided by member with no explanatory text

External inline image provided by member with no explanatory text

The scooter was working as a prop during the winter in a local grocery store during Italy theme month.
External inline image provided by member with no explanatory text

Fetched her from the winter storage. Getting along nicely with younger smallie cousins, but is bit jealous of having only about one fourth of the HP of the white one.
External inline image provided by member with no explanatory text

There was pretty bad leak between the cylinder and head.
External inline image provided by member with no explanatory text

No wonder, since the recess on the cylinder was around 2mm deep while the lip on the head was only about 1mm high. Sheet of 1mm alu plate trimmed to right size and shape to seal it up.
External inline image provided by member with no explanatory text

External inline image provided by member with no explanatory text

Cleaning of the mating surfaces, dab of sealant on both sides of the ring and it's fixed.
External inline image provided by member with no explanatory text

I have a hunch that this scoot does not have to be jealous of the white smallie's power in the future.
External inline image provided by member with no explanatory text

External inline image provided by member with no explanatory text
⚠️ Last edited by FINYoshi on UTC; edited 5 times
UTC

Veni, Vidi, Posti
Joined: UTC
Posts: 6683
Location: Tega Cay, SC

Veni, Vidi, Posti
Joined: UTC
Posts: 6683
Location: Tega Cay, SC
UTC quote
Fantastic write-up and, wow what a nice ride you have there! Great job, you should be proud.
@chandlerman avatar
UTC

Lucky
76 Sprint V, 63 GL, 62 VBB, 05 Stella, 66 Smallstate, 79 P200E, 66 Lammy S3
Joined: UTC
Posts: 9734
Location: Nashville

17 Days Since Last Explosion

Lucky
@chandlerman avatar
76 Sprint V, 63 GL, 62 VBB, 05 Stella, 66 Smallstate, 79 P200E, 66 Lammy S3
Joined: UTC
Posts: 9734
Location: Nashville

17 Days Since Last Explosion
UTC quote
And the Summer of Citrus continues! I love it!

What the hell kind of crazy Finnish mice are y'all raising up there chewed through that tunnel, though? Laughing emoticon
@qascooter avatar
UTC

Ossessionato
79 P200E (Ruby), 62 Allstate (B-62)
Joined: UTC
Posts: 4234
Location: Florence, OR

Ossessionato
@qascooter avatar
79 P200E (Ruby), 62 Allstate (B-62)
Joined: UTC
Posts: 4234
Location: Florence, OR
UTC quote
WOW, just WOW Clap emoticon Clap emoticon Clap emoticon Clap emoticon Clap emoticon
@108 avatar
UTC

Ossessionato
V range 50s
Joined: UTC
Posts: 2392

Ossessionato
@108 avatar
V range 50s
Joined: UTC
Posts: 2392
UTC quote
Looking forward to seeing the Malossi cases…!

Haven't seen those in action yet, all end up being half finished projects
@bobo avatar
UTC

Ossessionato
'70 Super 150, Medley 150S, '23 Ducati Monster SP
Joined: UTC
Posts: 2533
Location: Sydney, Australia

Ossessionato
@bobo avatar
'70 Super 150, Medley 150S, '23 Ducati Monster SP
Joined: UTC
Posts: 2533
Location: Sydney, Australia
UTC quote
Excellent.
@geeklion avatar
UTC

The Dude
Too Many piles of Junk that need too much work and too much money
Joined: UTC
Posts: 1655
Location: PNW from LBC

The Dude
@geeklion avatar
Too Many piles of Junk that need too much work and too much money
Joined: UTC
Posts: 1655
Location: PNW from LBC
UTC quote
Nice work! love the color. Summer of Citrus is on Clap emoticon Clap emoticon Clap emoticon
@ray8 avatar
UTC

Molto Verboso
Joined: UTC
Posts: 1853
Location: Los Angeles

Molto Verboso
@ray8 avatar
Joined: UTC
Posts: 1853
Location: Los Angeles
UTC quote
So awesome!
Thanks so much for this.

Can I ask what type of body filler if any you used under the powder coat?
OP
@finyoshi avatar
UTC

Addicted
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland

Addicted
@finyoshi avatar
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland
UTC quote
No body filler at all.

I believe dents and dings belong to these things at some level since these scoots are definitely not new.
@hibbert avatar
UTC

Molto Verboso
Vespa
Joined: UTC
Posts: 1670
Location: California

Molto Verboso
@hibbert avatar
Vespa
Joined: UTC
Posts: 1670
Location: California
UTC quote
Where is the GL?
@socalguy avatar
UTC

bodgemaster
63 GL, 76 Super (x2), 74 Primavera (x2), 79 P200, 06 Fly 150
Joined: UTC
Posts: 7133
Location: So Cal

bodgemaster
@socalguy avatar
63 GL, 76 Super (x2), 74 Primavera (x2), 79 P200, 06 Fly 150
Joined: UTC
Posts: 7133
Location: So Cal
UTC quote
hibbert wrote:
Where is the GL?
Yeah, nice work but this isn't a GL
@cdevillasante avatar
UTC

Addicted
1979 P200, 1960 Lambretta s2, 1975 Rally 200
Joined: UTC
Posts: 544
Location: San Francisco Bay Area

Addicted
@cdevillasante avatar
1979 P200, 1960 Lambretta s2, 1975 Rally 200
Joined: UTC
Posts: 544
Location: San Francisco Bay Area
UTC quote
love it! great color looks so different depending on the light!
@xantufrog avatar
UTC

Moderibbit
1980 P200E - "Old Rusty", 1976 ET3 Primavera
Joined: UTC
Posts: 8892
Location: Atlanta, GA

Moderibbit
@xantufrog avatar
1980 P200E - "Old Rusty", 1976 ET3 Primavera
Joined: UTC
Posts: 8892
Location: Atlanta, GA
UTC quote
God this makes me want an orange scoot so bad - doesn't need to be a "GL"
OP
@finyoshi avatar
UTC

Addicted
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland

Addicted
@finyoshi avatar
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland
UTC quote
If this is not a GL, then what is it

VIN: VGLA1T044xx
@socalguy avatar
UTC

bodgemaster
63 GL, 76 Super (x2), 74 Primavera (x2), 79 P200, 06 Fly 150
Joined: UTC
Posts: 7133
Location: So Cal

bodgemaster
@socalguy avatar
63 GL, 76 Super (x2), 74 Primavera (x2), 79 P200, 06 Fly 150
Joined: UTC
Posts: 7133
Location: So Cal
UTC quote
I could be wrong but I don't think these were badged or marketed as "GL's". The cowls are different from the later models and it has a round headlight instead of a trap.

Not sure what Piaggio called these early 10" scoots. "Vespa 150 - Touring model"?
UTC

Member
'63 GL, '74 PV
Joined: UTC
Posts: 16
Location: Chicago

Member
'63 GL, '74 PV
Joined: UTC
Posts: 16
Location: Chicago
UTC quote
There was an earlier GL sold in northern Europe that looks different than the later GL that was sold ... mostly in the midwest USA.
@christopher_55934 avatar
UTC

Ossessionato
2007 Stella 225
Joined: UTC
Posts: 3547
Location: Rochester, Minnesota

Ossessionato
@christopher_55934 avatar
2007 Stella 225
Joined: UTC
Posts: 3547
Location: Rochester, Minnesota
UTC quote
FINYoshi wrote:
If this is not a GL, then what is it

VIN: VGLA1T044xx
Says GL 150

https://www.scooterhelp.com/scooters/VGLA1T.gl.html

https://www.vespa.name/vespa-model/vespa-150-gl
@waspmike avatar
UTC

Ossessionato
LXV 150 3v ie. Midnight Blue (Sold) Now Honda Zoomer X
Joined: UTC
Posts: 4125
Location: Kingdom of Lanna

Ossessionato
@waspmike avatar
LXV 150 3v ie. Midnight Blue (Sold) Now Honda Zoomer X
Joined: UTC
Posts: 4125
Location: Kingdom of Lanna
UTC quote
External inline image provided by member with no explanatory text
OP
@finyoshi avatar
UTC

Addicted
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland

Addicted
@finyoshi avatar
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland
UTC quote
The_PS wrote:
There was an earlier GL sold in northern Europe that looks different than the later GL that was sold ... mostly in the midwest USA.
I bought a restoration kit for GL 150 and it came with mostly correct parts. It had a trap headlight chrome ring and black "Vespa GL" badge. Since it's a finnish scoot, this seems to be the case.
Christopher_55934 wrote:
Says GL 150
These are the exact links I based my identification on when registering the scoot
waspmike wrote:
Bottle of Fast Orange
You got it! I've humoured myself about contacting Permatex and asking if they were willing to chip in on the engine and have their logos taped on the scoot. Could go something like this: "Now the scooter is orange, would you help me make it Fast Orange?"
@vespistaforever avatar
UTC

Enthusiast
1952 faro basso,P200E, Allstate, ET3, V98, Vespa Bacchetta, 1954 Allstate
Joined: UTC
Posts: 66
Location: Garland tx

Enthusiast
@vespistaforever avatar
1952 faro basso,P200E, Allstate, ET3, V98, Vespa Bacchetta, 1954 Allstate
Joined: UTC
Posts: 66
Location: Garland tx
UTC quote
FINYoshi wrote:
If this is not a GL, then what is it

VIN: VGLA1T044xx
Back in January 1955 Piaggio Vespa were also assembled in Bruxel , Belgium by local company "Motor Industry S.A. These model of Vespa VGLA were made in 1959 by M.I.S.A . Was marketed only in northern Europe, mainly Scandinavia. This is not a Vespa GL
OP
@finyoshi avatar
UTC

Addicted
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland

Addicted
@finyoshi avatar
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland
UTC quote
The question still lingers: what is it then

This scooter is older than my parents so I don't have much first hand info on the subject. This is why I'm basing my research on the Internet and of course that info can be false.

This one looks to be same. My scooter also had those side cover trims but they were broken and I did not install them. Mine has a 4 speed gearbox and selector on the headset though.
[Piteå, Sweden] VESPA VGLA 150 cc 1959

For what I've read, this is basically an Italian made, Scandinavian import version of VBA. Equipped with front fender and 10" wheels from a 150 GS. These are known as GL's over here since we are kind of pagans of the Vespa world Laughing emoticon
@socalguy avatar
UTC

bodgemaster
63 GL, 76 Super (x2), 74 Primavera (x2), 79 P200, 06 Fly 150
Joined: UTC
Posts: 7133
Location: So Cal

bodgemaster
@socalguy avatar
63 GL, 76 Super (x2), 74 Primavera (x2), 79 P200, 06 Fly 150
Joined: UTC
Posts: 7133
Location: So Cal
UTC quote
"The idea for a mid-line scooter had been around for quite awhile before Piaggio decided to make a separately styled model. Early versions were manufactured for specific European markets, and were basically a standard Vespa 150 with larger 10" wheels. They did not have any model specific styling or badging. One notable example of this early "G.L." would be the German market "Vespa Touring," of which many were made."

http://www.scooterlounge.com/vespa/buyers-guide/vespa-gl.shtml
OP
@finyoshi avatar
UTC

Addicted
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland

Addicted
@finyoshi avatar
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland
UTC quote
According to that, it is a GL after all. Just an early variant which later shaped into a more produced and widerly known GL.
@socalguy avatar
UTC

bodgemaster
63 GL, 76 Super (x2), 74 Primavera (x2), 79 P200, 06 Fly 150
Joined: UTC
Posts: 7133
Location: So Cal

bodgemaster
@socalguy avatar
63 GL, 76 Super (x2), 74 Primavera (x2), 79 P200, 06 Fly 150
Joined: UTC
Posts: 7133
Location: So Cal
UTC quote
No, those early models weren't marketed as GLs. They didn't have a trap headset, didn't have the distinctive GL paint scheme, didn't have the GL tail light, didn't have GL cowls and most importantly didn't have a badge that said "GL".

Not to say it isn't a beautiful scoot. Like the scooter lounge article says, they were basically a standard Vespa 150 with 10" wheels and no specific model styling.

I suppose you could call them "proto GLs".
OP
@finyoshi avatar
UTC

Addicted
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland

Addicted
@finyoshi avatar
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland
UTC quote
Thanks for the feedback on all sides. I've now edited the title to better represent the model of the scooter.
@christopher_55934 avatar
UTC

Ossessionato
2007 Stella 225
Joined: UTC
Posts: 3547
Location: Rochester, Minnesota

Ossessionato
@christopher_55934 avatar
2007 Stella 225
Joined: UTC
Posts: 3547
Location: Rochester, Minnesota
UTC quote
One thing I've learned over the years, especially living in Japan for 4 years. What is a model in one country may not exist in another. Even if it rolls off same assembly line. Don't get hung up on a model and enjoy your scooter. I have a Saturn Sky made in Wilmington Delaware, only plant to make Kappa chassis. It's also on Opal GT, G2X Roadster, Pontiac Solstice same frame different body and interior, parts mix and match. Oh and the headlights are different among a few of them.
OP
@finyoshi avatar
UTC

Addicted
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland

Addicted
@finyoshi avatar
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland
UTC quote
Yep! What ever it is, it's my favorite scoot this far. Love the thicc booty and round curves on the front
@vespistaforever avatar
UTC

Enthusiast
1952 faro basso,P200E, Allstate, ET3, V98, Vespa Bacchetta, 1954 Allstate
Joined: UTC
Posts: 66
Location: Garland tx

Enthusiast
@vespistaforever avatar
1952 faro basso,P200E, Allstate, ET3, V98, Vespa Bacchetta, 1954 Allstate
Joined: UTC
Posts: 66
Location: Garland tx
UTC quote
FINYoshi wrote:
According to that, it is a GL after all. Just an early variant which later shaped into a more produced and widerly known GL.
I have sent you a note on a different post, Your bike a 1959 Vespa MISA made in Belgium
⚠️ Last edited by VespistaForever on UTC; edited 1 time
OP
@finyoshi avatar
UTC

Addicted
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland

Addicted
@finyoshi avatar
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland
UTC quote
What I've read the scoots made by M.I.SA in Belgium should have a specific type-badge in addition to frame number which these scandinavian ones do not have.

Found this picture which shows the "Popolino". Text in swedish says it is a special series made in Italy for swedish regulations for under 16 year olds to ride. Weight under 75kg. Also mentions the model Touring.
External inline image provided by member with no explanatory text

Here is stated that Popolino is technically identical to Elit with 125cc engine and 5hp
External inline image provided by member with no explanatory text

Then for the most interesting one which really tells what this really is. Could not find any Finnish ads so this might be as close as I can get.
External inline image provided by member with no explanatory text
@vespistaforever avatar
UTC

Enthusiast
1952 faro basso,P200E, Allstate, ET3, V98, Vespa Bacchetta, 1954 Allstate
Joined: UTC
Posts: 66
Location: Garland tx

Enthusiast
@vespistaforever avatar
1952 faro basso,P200E, Allstate, ET3, V98, Vespa Bacchetta, 1954 Allstate
Joined: UTC
Posts: 66
Location: Garland tx
UTC quote
FINYoshi wrote:
What I've read the scoots made by M.I.SA in Belgium should have a specific type-badge in addition to frame number which these scandinavian ones do not have.

Found this picture which shows the "Popolino". Text in swedish says it is a special series made in Italy for swedish regulations for under 16 year olds to ride. Weight under 75kg. Also mentions the model Touring.
External inline image provided by member with no explanatory text

Here is stated that Popolino is technically identical to Elit with 125cc engine and 5hp
External inline image provided by member with no explanatory text

Then for the most interesting one which really tells what this really is. Could not find any Finnish ads so this might be as close as I can get.
External inline image provided by member with no explanatory text
The MISA did not have a specific badge, just different color than the usual Vespa. I use to sell them When I use to leave in Italy. Vespa GL prefix is VLA1T.
VGLA1T is different and is related to the Vespa Misa.
⬆️    About 2 months elapsed    ⬇️
OP
@finyoshi avatar
UTC

Addicted
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland

Addicted
@finyoshi avatar
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland
UTC quote
Orange got some attention in form of a new seat to replace the old PX saddle with torn cover. It's an original Piaggio seat from 98 model and was relatively cheap at ~100eur. Literally was, since now the price has gone up to 159eur
External inline image provided by member with no explanatory text
OP
@finyoshi avatar
UTC

Addicted
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland

Addicted
@finyoshi avatar
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland
UTC quote
Wanted to take the orange one for a ride but could not get it running for some reason. Finally started up after giving a squirt of brake cleaner to the carb and ran happily after that. In the summer I had hard time starting when the engine was warm.
External inline image provided by member with no explanatory text

Original 150 engine has to be overhauled anyway so I decided to replace it with budget big block motor. It will eventually find it's way to Bajaj after the VR-One engine is built.
External inline image provided by member with no explanatory text

It's such a breeze to swap the engine on a largeframe.
External inline image provided by member with no explanatory text

I like the black look a lot better than the frame colored cylinder hood and fan cover.
External inline image provided by member with no explanatory text
OP
@finyoshi avatar
UTC

Addicted
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland

Addicted
@finyoshi avatar
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland
UTC quote
Some wiring, color coded of course to take out the guesswork Laughing emoticon
External inline image provided by member with no explanatory text

Engine in and cabled up
External inline image provided by member with no explanatory text

Exhaust was hanging about 3cm too low and would have been impossible to get the retaining bolt through the engine mount. Took the good ol' method of angle grinder and welder. Cut the exhaust in two pieces right next to the cylinder end clamp, mountend all up and tacked the parts together. Finished off on the table and fixed couple cracks from the pipe and box joint.
External inline image provided by member with no explanatory text

Went off to take couple pictures in the beautiful colors of the fall
External inline image provided by member with no explanatory text

External inline image provided by member with no explanatory text
OP
@finyoshi avatar
UTC

Addicted
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland

Addicted
@finyoshi avatar
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland
UTC quote
I think it sounds reasonably happy with the jetting that was already in the carb. I haven't even touched the mix screw yet, just dialed in the idle screw so it runs without stalling.

Currently the carb setup is 160 AC, BE3, 116 MJ, 50/160 idle.

External inline image provided by member with no explanatory text
@108 avatar
UTC

Ossessionato
V range 50s
Joined: UTC
Posts: 2392

Ossessionato
@108 avatar
V range 50s
Joined: UTC
Posts: 2392
UTC quote
The India gearbox looks great!

And yes… largeframes are way easier… there's actually space to put your hands to work on them… lol
OP
@finyoshi avatar
UTC

Addicted
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland

Addicted
@finyoshi avatar
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland
UTC quote
Took the scoot inside the shed because of the rain outside for finishing touches. Swapped bulbs out to 12V ones, checked the function of refulator, adjusted the wiring and replaced the god-knows-how-old front tire with a fresh Michelin S83.

External inline image provided by member with no explanatory text
OP
@finyoshi avatar
UTC

Addicted
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland

Addicted
@finyoshi avatar
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland
UTC quote
Now there are two torque-monsters side by side
External inline image provided by member with no explanatory text
@sdjohn avatar
UTC

Veni, Vidi, Posti
'15 GTS300, '86 PX125EFL, '66 VBB, '01 ET4
Joined: UTC
Posts: 8380
Location: San Diego, CA

Veni, Vidi, Posti
@sdjohn avatar
'15 GTS300, '86 PX125EFL, '66 VBB, '01 ET4
Joined: UTC
Posts: 8380
Location: San Diego, CA
UTC quote
citrus to the max
@chandlerman avatar
UTC

Lucky
76 Sprint V, 63 GL, 62 VBB, 05 Stella, 66 Smallstate, 79 P200E, 66 Lammy S3
Joined: UTC
Posts: 9734
Location: Nashville

17 Days Since Last Explosion

Lucky
@chandlerman avatar
76 Sprint V, 63 GL, 62 VBB, 05 Stella, 66 Smallstate, 79 P200E, 66 Lammy S3
Joined: UTC
Posts: 9734
Location: Nashville

17 Days Since Last Explosion
UTC quote
sdjohn wrote:
citrus to the max
+1!
⬆️    About 2 months elapsed    ⬇️
OP
@finyoshi avatar
UTC

Addicted
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland

Addicted
@finyoshi avatar
Parmakit Primavera -74, Polini Primavera -68, VR-One 228 150 Touring -59, VMC 177 Bajaj Chetak 125 -95
Joined: UTC
Posts: 543
Location: Finland
UTC quote
Shot a clip of launching this thing. Pretty underwhelming with the stock exhaust, but a new polini box is already on it's way Razz emoticon

External inline image provided by member with no explanatory text
DoubleGood Design banner

Modern Vespa is the premier site for modern Vespa and Piaggio scooters. Vespa GTS300, GTS250, GTV, GT200, LX150, LXS, ET4, ET2, MP3, Fuoco, Elettrica and more.

Buy Me A Coffee


Shop on Amazon with Modern Vespa

Modern Vespa is a participant in the Amazon Services LLC Associates Program, an affiliate advertising program designed to provide a means for sites to earn advertising fees by advertising and linking to amazon.com


All Content Copyright 2005-2024 by Modern Vespa.
All Rights Reserved.


[ Time: 0.0095s ][ Queries: 3 (0.0022s) ][ live ][ 313 ][ ThingOne ]
